Standard Metal Zipper

TRC standard metal zipper uses high-strength brass or nickel teeth, giving it excellent wear resistance, wash resistance, and heat-resistant ironing performance. In addition, it is available in popular colors such as champagne gold, making it widely suitable for jeans, jackets, and various other types of clothing.

Send Inquiry

Product Description

TRC standard metal zippers are crafted with high-quality brass or nickel teeth for exceptional strength, abrasion resistance, and durability. They withstand frequent use, washing, and high-temperature ironing, maintaining smooth operation and a refined appearance even after extended wear.

TRC standard metal zippers are available in a variety of colors, including classic brass, nickel, and champagne gold, and blend seamlessly with jeans, jackets, leather goods, and workwear. This product ensures secure tooth engagement and precise alignment, significantly improving both functionality and aesthetics.

As a trusted zipper manufacturer in China, TRC's products are widely recognised for their reliability, corrosion resistance, and consistent performance, establishing them as the preferred choice for apparel brands and global fashion manufacturers.

To meet partners' diverse requirements, TRC offers extensive customisation options including zipper length, tape colour, tooth material, plating finish, and slider style. Whether for jeans, outerwear, or heavy-duty garments, TRC metal zips deliver enduring performance.

Specification:

Size/End-type
Model	Classification
Model	Close End	Open End	2 Way Close End	2 Way Open End	Chain
3.5M	√	√	√	√	√
4M	√	×	×	√	√
5M	√	√	√	√	√
8M	√	√	√	√	√
10M	√	√	√	√	√

Product Details：

Property Parameters：

3.5M Metal Zipper Standard	QB/T2171-2014 Standard	TRC Properties	DIN3419 Standard
Chain Crosswise	≧380	≧380	≧425
Tap Pull-Off Strength	≦3	≦3	/
Holding Strength Of Top Stop	≧78	≧78	≧60
Holding Strength Of Bottom Stop	≧50	≧50	/
Bottom Stop Holding,Crosswise Test	/	≧40	≧40
Open-End Fastener Single Stringer Slider Retention Test	≧50	≧50	/
Holding Strength Of Separating Unit,Crosswise Test / Chain Crosswise Strength	≧80	≧80	≧70
Holding Strength Of Fixed Retainer Pull-Off Test/ Box Slippage Strength	≧80	≧80	≧60
Pin Slippate Strength	≧60	≧60	/
Resistance To Pull-Off Slider Pull	≧120	≧120	≧70
Resistance To Twist Of Puller And Slider（N.M）	≧0.2	≧0.2	/
Deflection Strength	≧42	≧42	/
Slider Lock Holding, Stringer Separation	≧30	≧30	/
Scoop Slippage, Lengthwise	≧40	≧40	/
Individual Scoop Pull Off	/	≧35	≧40
Reciprocation Test(Double)	≧600	≧600	/

4M Metal Zipper Standard	QB/T2171-2014 Standard	TRC Properties	DIN3419 Standard
Chain Crosswise	≧425	≧425	≧500
Tap Pull-Off Strength	≦3.5	≦3	/
Holding Strength Of Top Stop	≧80	≧80	≧80
Holding Strength Of Bottom Stop	≧60	≧60	/
Bottom Stop Holding,Crosswise Test	/	≧40	≧40
Open-End Fastener Single Stringer Slider Retention Test	≧60	≧60	/
Holding Strength Of Separating Unit,Crosswise Test / Chain Crosswise Strength	≧100	≧100	≧100
Holding Strength Of Fixed Retainer Pull-Off Test/ Box Slippage Strength	≧90	≧90	≧80
Pin Slippate Strength	≧65	≧65	/
Resistance To Pull-Off Slider Pull	≧150	≧150	120-150
Resistance To Twist Of Puller And Slider（N.M）	≧0.3	≧0.3	/
Deflection Strength	≧58	≧58	/
Slider Lock Holding, Stringer Separation	≧50	≧50	/
Scoop Slippage, Lengthwise	≧45	≧45	/
Individual Scoop Pull Off	/	≧40	≧50
Reciprocation Test(Double)	≧600	≧600	/

5M Metal Zipper Standard	QB/T2171-2014 Standard	TRC Properties	DIN3419 Standard
Chain Crosswise	≧500	≧500	≧500
Tap Pull-Off Strength	≦4	≦3.5	/
Holding Strength Of Top Stop	≧100	≧100	≧80
Holding Strength Of Bottom Stop	≧80	≧80	/
Bottom Stop Holding,Crosswise Test	/	≧55	≧55
Open-End Fastener Single Stringer Slider Retention Test	≧70	≧70	/
Holding Strength Of Separating Unit,Crosswise Test / Chain Crosswise Strength	≧120	≧120	≧100
Holding Strength Of Fixed Retainer Pull-Off Test/ Box Slippage Strength	≧100	≧100	≧80
Pin Slippate Strength	≧80	≧80	/
Resistance To Pull-Off Slider Pull	≧200	≧200	120-150
Resistance To Twist Of Puller And Slider（N.M）	≧0.45	≧0.45	/
Deflection Strength	≧60	≧60	/
Slider Lock Holding, Stringer Separation	≧60	≧60	/
Scoop Slippage, Lengthwise	≧50	≧50	/
Individual Scoop Pull Off	/	≧50	≧50
Reciprocation Test(Double)	≧600	≧600	/

8M Metal Zipper Standard	QB/T2171-2014 Standard	TRC Properties	DIN3419 Standard
Chain Crosswise	≧650	≧700	≧650
Tap Pull-Off Strength	≦6.5	≦5	/
Holding Strength Of Top Stop	≧150	≧150	≧120
Holding Strength Of Bottom Stop	≧150	≧150	/
Bottom Stop Holding,Crosswise Test	/	≧130	≧120
Open-End Fastener Single Stringer Slider Retention Test	≧100	≧100	/
Holding Strength Of Separating Unit,Crosswise Test / Chain Crosswise Strength	≧180	≧180	≧150
Holding Strength Of Fixed Retainer Pull-Off Test/ Box Slippage Strength	≧130	≧130	≧120
Pin Slippate Strength	≧100	≧100	/
Resistance To Pull-Off Slider Pull	≧250	≧250	200-250
Resistance To Twist Of Puller And Slider（N.M）	≧0.8	≧0.8	/
Deflection Strength	≧75	≧75	/
Slider Lock Holding, Stringer Separation	≧90	≧90	/
Scoop Slippage, Lengthwise	≧90	≧90	/
Individual Scoop Pull Off	/	≧90	≧100
Reciprocation Test(Double)	≧600	≧600	/

10M Metal Zipper Standard	QB/T2171-2014 Standard	TRC Properties	DIN3419 Standard
Chain Crosswise	≧800	≧800	≧800
Tap Pull-Off Strength	≦7	≦6	/
Holding Strength Of Top Stop	≧160	≧160	≧150
Holding Strength Of Bottom Stop	≧180	≧180	/
Bottom Stop Holding,Crosswise Test	/	≧150	≧150
Open-End Fastener Single Stringer Slider Retention Test	≧120	≧120	/
Holding Strength Of Separating Unit,Crosswise Test / Chain Crosswise Strength	≧200	≧200	≧180
Holding Strength Of Fixed Retainer Pull-Off Test/ Box Slippage Strength	≧150	≧150	≧120
Pin Slippate Strength	≧120	≧120	/
Resistance To Pull-Off Slider Pull	≧300	≧300	250-300
Resistance To Twist Of Puller And Slider（N.M）	≧0.9	≧0.9	/
Deflection Strength	≧80	≧80	/
Slider Lock Holding, Stringer Separation	≧100	≧100	/
Scoop Slippage, Lengthwise	≧120	≧120	/
Individual Scoop Pull Off	/	≧120	≧120
Reciprocation Test(Double)	≧600	≧600	/

Tips：

Special fabrics process

– Chemical reactions will take place easily between the surface of the copper alloy and the chemical residues in the fabric that are introduced in the dyeing and finishing process. Take the sulfur black fabrics for example. Oxidation and color change will take place easily on the zipper surface, following the washing process applied to the trousers if the fabric is not fully cleaned before the installation of the zipper.

– In this case, the zipper should be wrapped with a piece of cloth, followed by the sample test carried out in the simulated washing environment. If any color change takes place on the zipper surface or if any unexpected mark is left in the place where the fabric and teeth meet, cleaning and drying should be applied to the fabric prior to tailoring.

If there is any doubt about the color washing, a simulated washing test should be carried out prior to the bulk production.

Special washing process

– Reactions will take place easily between the copper alloy of the zipper and the external chemicals during the chemical reprocessing process applied to the fabric and the zipper that has been installed, such as fade-dyeing, dyeing, bleaching, etc. A sample test should be carried out if any special washing process is involved in the post-treatment of the clothing. If any unexpected changes occur, please wrap the zipper surface to protect the metal part prior to washing.

Washing process

– The industrial washing process often involves a great many items simultaneously, which will result in relatively great torque. The zipper should be closed completely before washing in case of the excessive external force that is applied to the slider and teeth, which can cause the teeth to drop off.

Packing and Ironing

– The zippers should be dried prior to packaging in case the water vapor that remains after ironing is introduced into the packaging bags.

– A piece of paper or cloth should be laid between the zipper and the fabric prior to ironing to prevent the wax on the zipper surface from transferring to the fabric.

– Avoid storage in the high-temperature and damp environment.

– Avoid packaging in plastic and vinyl bags.

Application：

Pants/Jeans

Lady's Dress/Skirt

Tent

Formal Dress

Down Jacket

Ornament

Health

Sport/Outdoor

Jacket

Coat

Military

Light Fabrics

Home Decoration

Pet

Handbag

Shoes/Boots

Casual

Government

Cotton

Industrial

Children's Clothing

Luggage

Uniform

Warm Clothing

Protective Work Wear

Medical
